System Control
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. 4-15
ID073015 Non-Confidential
4.2.23 Miscellaneous operations
Table 4-22 shows the 32-bit wide miscellaneous operations.
4.2.24 Performance monitor registers
Table 4-23 shows the 32-bit wide performance monitor registers.
Table 4-22 Miscellaneous system control operations
CRn Op1 CRm Op2 Name Type Reset Description
c1 0 c1 3 VCR RW
0x00000000
Virtualization Control Register on page 4-34
c7 0 c0 4
NOP
a
WO - -
c13 0 c0 2 TPIDRURW RW - Software Thread ID registers
3 TPIDRURO
RW
b
-
4 TPIDRPRW RW -
a. This operation is performed by the
WFI
instruction. See Deprecated registers on page 4-2.
b. RO in User mode.
Table 4-23 Performance monitor registers
CRn Op1 CRm Op2 Name Type Reset Description
c90c120PMCR RW
0x41093000
Performance Monitor Control Register
1PMCNTENSETRW
0x00000000
Count Enable Set Register
2PMCNTENCLRRW
0x00000000
Count Enable Clear Register
3 PMOVSR RW - Overflow Flag Status Register
4 PMSWINC WO - Software Increment Register
5 PMSELR RW
0x00000000
Event Counter Selection Register
c13 0 PMCCNTR RW - Cycle Count Register
1 PMXEVTYPER RW - Event Type Selection Register
2 PMXEVCNTR RW - Event Count Registers
c14 0 PMUSERENR
RW
a
0x00000000
User Enable Register
1PMINTENSETRW
0x00000000
Interrupt Enable Set Register
2PMINTENCLRRW
0x00000000
Interrupt Enable Clear Register
a. RO in User mode.
