System Control
ARM DDI 0388I Copyright © 2008-2012 ARM. All rights reserved. 4-16
ID073015 Non-Confidential
4.2.25 Security Extensions registers
Table 4-24 shows the Security Extensions registers.
4.2.26 Preload Engine registers
Table 4-25 shows the preload engine registers.
Table 4-24 Security Extensions registers
CRn Op1 CRm Op2 Name Type Reset Description
c1 0 c1 0
SCR
ab
RW
0x00000000
Secure Configuration Register
1
SDER
a
RW
0x00000000
Secure Debug Enable Register on page 4-31
2NSACR
RW
c
-
d
Non-secure Access Control Register on page 4-32
c12 0 c0 0 VBAR RW
0x00000000
e
Vector Base Address Register
1 MVBAR RW - Monitor Vector Base Address Register
c1 0 ISR RO
0x00000000
Interrupt Status Register
a. No access in Non-secure state.
b. SCR[6] is not implemented, RAZ/WI.
c. This is RW in Secure state and RO in the Non-secure state.
d.
0x00000000
if NEON present and
0x0000C000
if NEON not present.
e. Only the secure version is reset to 0. The Non-secure version must be programmed by software.
Table 4-25 Preload engine registers
CRn Op1 CRm Op2 Name Type Reset Description
11 0 c0 0 PLEIDR
RO
a
- PLE ID Register on page 4-36
2PLEASR
RO
a
- PLE Activity Status Register on page 4-36
4PLEFSR
RO
a
- PLE FIFO Status Register on page 4-37
c1 0 PLEUAR Privileged R/W
User RO
- Preload Engine User Accessibility Register on page 4-38
1 PLEPCR Privileged R/W
User RO
- Preload Engine Parameters Control Register on
page 4-39
a. RAZ if the PLE is not present.
