Item (bank) Display Description Initial value User level
LSP (step 5)
(SP bank)
SP-5
Same as step 1 0 Simple,
standard,
advanced
PID group No. (step 5)
(SP bank)
PID.5
1 Standard,
advanced
Ramp (step 5)
(SP bank)
RMP.5
0.0
Soak time (step 5)
(SP bank)
TIM.5
0.0
LSP (step 6)
(SP bank)
SP-6
Same as step 1 0 Simple,
standard,
advanced
PID group No. (step 6)
(SP bank)
PID.6
1 Standard,
advanced
Ramp (step 6)
(SP bank)
RMP.6
0.0
Soak time (step 6)
(SP bank)
TIM.6
0.0
LSP (step 7)
(SP bank)
SP-7
Same as step 1 0 Simple,
standard,
advanced
PID group No. (step 7)
(SP bank)
PID.7
1 Standard,
advanced
Ramp (step 7)
(SP bank)
RMP.7
0.0
Soak time (step 7)
(SP bank)
TIM.7
0.0
LSP (step 8)
(SP bank)
SP-8
Same as step 1 0 Simple,
standard,
advanced
PID group No. (step 8)
(SP bank)
PID.8
1 Standard,
advanced
Ramp (step 8)
(SP bank)
RMP.8
0.0
Soak time (step 8)
(SP bank)
TIM.8
0.0
• Steps for as many LSP groups as are specified by
C30
(LSP system group) are
displayed for setting.
• “PID group No.” is not displayed and the setting cannot be changed if ON/OFF
control is enabled or if “PID group selection” is set as the “Operation type” of any
of internal contacts 1 to 5.
• 0.1 U in “ramp” means that the setting displayed has one more decimal place than
the number of decimal places set by “PV decimal point position.”
• If set to 0.0 U, the RAMP is skipped and the next SOAK begins. If the LSP of two
consecutive steps is the same, the RAMP is skipped and the next SOAK begins.
• If “soak time” is set to 0.0 or 0, the SOAK is skipped and the next RAMP begins.
