5-40
Chapter 5. Functions
SP ramp unit
The unit of the ramp’s slope in a step operation can be specified.
Item (bank) Display Description Initial value User level
SP ramp unit
(setup bank)
C 32
0: 0.1 U/s
1: 0.1 U/min
2: 0.1 U/h
1 Advanced
• 0.1 U means that the setting displayed has one more decimal place than the
number of decimal places set by “PV decimal point position.”
Examples
For a thermocouple input with a range of −200 to + 200 °C: 0.1 U = 0.1 °C
For DC voltage input with a range of 0.0 to 100.0: 0.1 U = 0.01
Handling Precautions
• For DC voltage input or DC current input with the 3-decimal place setting,
0.1 U = 0.0001.
However, regarding the SP up and down settings, all four digits that are
displayed are after the decimal point because this device can display only
four digits.
