Chapter 6. Displayed Items and Settings
DO assignment bank
Bank selection: DO
Display Item Description Initial
value
User
level
Notes
Ot1.1
Control output 1
operation type
0: Default output
1: MV ON/OFF status 1 (ON/OFF control
output, time proportional output,
heating time proportional output of
heating/cooling control)
2: MV ON/OFF status 2 (cooling time
proportional output of heating/
cooling control
3: Function 1, (A and B) or (C and D)
4: Function 2, (A or B) and (C or D)
5: Function 3, (A or B or C or D)
6: Function 4, (A and B and C and D)
0 2 Displayed if control output 1 is
set to relay output or voltage
pulse output by the model No.
For control output 1, the default
output is MV1.
Ot1.2
Control output 1
output assignment A
0: Normally open (normally off = 0)
1: Normally closed (normally on = 1)
2: Internal event 1
3: Internal event 2
4: Internal event 3
5: Internal event 4
6: Internal event 5
7 to 13: Invalid
14: MV ON/OFF status 1
15: MV ON/OFF status 2
16 to 17: Invalid
18: DI1
19: DI2
20 to 25: Invalid
26: Internal contact 1
27: Internal contact 2
28: Internal contact 3
29: Internal contact 4
30: Internal contact 5
31 to 33: Undefined
34: User-defined bit 1
35: User-defined bit 2
36: User-defined bit 3
37: User-defined bit 4
38: MANUAL
39: READY
40: Invalid
41: AT (Auto-Tuning)
42: During SP ramp
43: Invalid
44: Alarm
45: PV alarm
46: Invalid
47: [MODE] key status
48: Event output 1 terminal status
49: Control output 1 terminal status
14 2 Displayed if relay output or
voltage pulse output is set as
control output 1 by the model
No. and control output 1
operation type is set to one of
functions 1–4 (Ot1.1 > 2).
Ot1.3
Control output 1
output assignment B
0 2
Ot1.4
Control output 1
output assignment C
0 2
Ot1.5
Control output 1
output assignment D
0 2
