Chapter 6. Displayed Items and Settings
Event configuration bank
Bank selection: EVCF
Display Item Description Initial
value
User
level
Notes
E1.C1
Internal event 1
conf. 1 operation
type
0: No event
1: PV high limit
2: PV low limit
3: PV high and low limits
4: Deviation high limit
5: Deviation low limit
6: Deviation high and low limits
7: Deviation high limit (final SP reference)
8: Deviation low limit (final SP reference)
9: Deviation high and low limits (final SP
reference)
10: SP high limit
11: SP low limit
12: SP high and low limits
13: MV high limit
14: MV low limit
15: MV high and low limits
16: Heater 1 burnout/overcurrent
17: Heater 1 short circuit
18: Heater 2 burnout/overcurrent
19: Heater 2 short circuit
20: Loop diagnosis 1
21: Loop diagnosis 2
22: Loop diagnosis 3
23: Alarm (status)
24: READY (status)
25: MANUAL (status)
26: Invalid
27: AT in execution (status)
28: During SP ramp (status)
29: Control direct action (status)
30: Invalid
31: Invalid
32: Timer (status)
33: Invalid
0 0
E1.C2
Internal event 1
conf. 2
“1st digit” (2nd, etc.) means the first digit
(etc.) from the right.
0
1st digit:
Direct/reverse
0: Direct
1: Reverse
0
2nd digit: Standby 0: None
1: Standby
2: Standby + standby when the SP is
changed
0
3rd digit:
Event state in
READY mode
0: Continues
1: Forced OFF
0
4th digit: Undefined 0 0
