Azbil C1M - Output Assignment

5-72
Chapter 5. Functions

Output assignment
The four inputs (A, B, C, D) used for output bit functions can be selected.
Item (bank) Display Description Initial value User level
Control output 1 output assignment A
(DO assignment bank)
Ot1.2
0: Normally open (normally off = 0)
1: Normally closed (normally on = 1)
2: Internal event 1
3: Internal event 2
4: Internal event 3
5: Internal event 4
6: Internal event 5
7 to 13: Undefined
14: MV1 ON/OFF status
15: MV2 ON/OFF status
16 to 17: Undefined
18: DI1
19: DI2
20 to 25: Undefined
26: Internal contact 1
27: Internal contact 2
28: Internal contact 3
29: Internal contact 4
30: Internal contact 5
31 to 33: Undefined
34: User-defined bit 1
35: User-defined bit 2
36: User-defined bit 3
37: User-defined bit 4
38: MANUAL mode
39: READY mode
40: Undefined
41: AT (Auto-Tuning)
42: During SP ramp
43: Undefined
44: Alarm (AL01 to AL96)
45: PV alarm (AL01 to AL03)
46: Undefined
47: [MODE] key status
48: Event output 1 terminal status
49: Control output 1 terminal status
14 Advanced
Control output 1 output assignment B
(DO assignment bank)
OT1.3
0
Control output 1 output assignment C
(DO assignment bank)
OT1.4
0
Control output 1 output assignment D
(DO assignment bank)
OT1.5
0
Control output 2 output assignment A
(DO assignment bank)
OT2.2
15
Control output 2 output assignment B
(DO assignment bank)
OT2.3
0
Control output 2 output assignment C
(DO assignment bank)
OT2.4
0
Control output 2 output assignment D
(DO assignment bank)
OT2.5
0
Event output 1 output assignment A
(DO assignment bank)
EV1.2
2
Event output 1 output assignment B
(DO assignment bank)
EV1.3
0
Event output 1 output assignment C
(DO assignment bank)
EV1.4
0
Event output 1 output assignment D
(DO assignment bank)
EV1.5
0
Event output 2 output assignment A
(DO assignment bank)
EV2.2
3
Event output 2 output assignment B
(DO assignment bank)
EV2.3
0
Event output 2 output assignment C
(DO assignment bank)
EV2.4
0
Event output 2 output assignment D
(DO assignment bank)
EV3.5
0
Event output 3 output assignment A
(DO assignment bank)
EV3.2
4
Event output 3 output assignment B
(DO assignment bank)
EV3.3
0
Event output 3 output assignment C
(DO assignment bank)
EV3.4
0
Event output 3 output assignment D
(DO assignment bank)
EV3.5
0
