Azbil C1M - User-Defined Function

5-99
Chapter 5. Functions

User-defined function
Up to eight more settings selected from various settings can be displayed as user-
defined functions 1–8 on the operation display.
Item (bank) Display Description Initial value User level
User function 1
(user function bank)
UF-1
Displayed characters are defined for each item. The
following are special cases.
----
: Unregistered
P- _
: Proportional band of the PID in use
I-_
: Integral time of the PID in use
d- _
: Derivative time of the PID in use
rE- _
: Manual reset of the PID in use
OL- _
: MV low limit of the PID in use
OH- _
: MV high limit of the PID in use
P- _ C
: Proportional band for cooling of the PID in use
I- _ C
: Integral time for cooling of the PID in use
d- _ C
: Derivative time for cooling of the PID in use
OL. _ C
: MV low limit for cooling of the PID in use
OH. _ C
: MV high limit for cooling of the PID in use
---- Standard,
advanced
User function 2
(user function bank)
UF-2
----
User function 3
(user function bank)
UF-3
----
User function 4
(user function bank)
UF-4
----
User function 5
(user function bank)
UF-5
----
User function 6
(user function bank)
UF-6
----
User function 7
(user function bank)
UF-7
----
User function 8
(user function bank)
UF-8
----
• Only the settings that can be displayed can be registered.
(Example: Manual reset of the PID constants can be registered when integral time
= 0)
• Items cannot be registered from the console using the parameter number
displayed on the setup screen of Smart Loader Package model SLP-C1F.
• To select a parameter, use the keys as follows.
[<]: Displays the first parameter in the next bank.
[∨]: Displays the next parameter.
[∧]: Displays the previous parameter.
Handling Precautions
• The user level required for user-defined functions 1–8 to be shown on the
operation display is “advanced.”
