Chapter 5. Functions
PV decimal point position
If the PV input type is DC voltage/current, or if some thermocouple or RTD range
types are selected, the decimal point position of the PV input can be specified.
Item (bank) Display Description Initial value User level
PV decimal point position
(setup bank)
C 04
0: No decimal point
1: 1 digit after the decimal point
2: 2 digits after the decimal point
3: 3 digits after the decimal point
0 Simple,
standard,
advanced
Handling Precautions
• This setting also applies to other parameters, including those listed
below.
•
SP
•
SP low limit / high limit
•
SP up ramp / down ramp
•
PV range low limit / high limit
•
Event setting and continuous output setting related to PV
•
Event setting and continuous output setting related to SP
•
Event settings and continuous output settings related to deviation
(absolute deviation)
•
ON/OFF control differential
•
ON/OFF control operating point offset
•
MV switching point PV in AT
Note
•
PV input range type (p.5-2) (for whether this item is displayed for a
certain C01 setting. The setting range and initial value also vary depending
on the setting.)
