Azbil C1M - DI Assignment Bank

6-28
Chapter 6. Displayed Items and Settings

DI assignment bank
Bank selection: DI
Display Item Description Initial
value
User
level
Notes
DI1.1
Internal contact 1
operation type
0: No function
1: LSP group selection (0/+1)
2: LSP group selection (0/+2)
3: LSP group selection (0/+4)
4: PID group selection (0/+1)
5: PID group selection (0/+2)
6: PID group selection (0/+4)
7: RUN/READY selection
8: AUTO/MANUAL selection
9: Invalid
10: AT stop/start
11: Invalid
12: Control operation (direct/reverse)
(Operates as configured / reversed
operation)
13: SP ramp enabling/disabling
14: PV hold
(disabled/enabled)
15: PV max. hold
(disabled/enabled)
16: PV min. hold
(disabled/enabled)
17: Timer stop/start
18: Release/continue all DO latches
19: Advance (disabled/enabled)
20: SP step hold
(disabled/enabled)
0 0
DI1.2
Internal contact 1
input bit function
0: Not used (use the default input)
1: Function 1, (A and B) or (C and D)
2: Function 2, (A or B) and (C or D)
3: Function 3, (A or B or C or D)
4: Function 4, (A and B and C and D)
0 2 If a model with digital inputs is
used, if 0 (not used) is selected,
internal contact 1 reflects the
state of digital input 1.
