5-44
Chapter 5. Functions

Step operation: LSP, PID group No., ramp, soak time
How to change the SP during a step operation and PID group No. can be specified.
Item (bank) Display Description Initial value User level
LSP (step 1)
(SP bank)
SP-1
SP low limit (C07) to SP high limit (C08)
0 Simple,
standard,
advanced
PID group No. (step 1)
(SP bank)
PID.1
1 to 8 1 Standard,
advanced
Ramp (step 1)
(SP bank)
RMP.1
0.0 U : No ramp
0.1 to 999.9 U (Select the time unit of the
ramp by “SP ramp unit.”)
0.0
Soak time (step 1)
(SP bank)
TIM.1
0.0 to 999.9 s
(when “STEP time unit” = 0.1 s)
0 to 9999 s
(when “STEP time unit” = 1 s)
0 to 9999 min
(when “STEP time unit” = 1 min)
0.0
LSP (step 2)
(SP bank)
SP-2
Same as step 1 0 Simple,
standard,
advanced
PID group No. (step 2)
(SP bank)
PID.2
1 Standard,
advanced
Ramp (step 2)
(SP bank)
RMP.2
0.0
Soak time (step 2)
(SP bank)
TIM.2
0.0
LSP (step 3)
(SP bank)
SP-3
Same as step 1 0 Simple,
standard,
advanced
PID group No. (step 3)
(SP bank)
PID.3
1 Standard,
advanced
Ramp (step 3)
(SP bank)
RMP.3
0.0
Soak time (step 3)
(SP bank)
TIM.3
0.0
LSP (step 4)
(SP bank)
SP-4
Same as step 1 0 Simple,
standard,
advanced
PID group No. (step 4)
(SP bank)
PID.4
1 Standard,
advanced
Ramp (step 4)
(SP bank)
RMP.4
0.0
Soak time (step 4)
(SP bank)
TIM.4
0.0
