Chapter 5. Functions

Function result polarity
Whether to reverse the results of output bit functions 1 to 4 can be specified.
Item (bank) Display Description Initial value User level
Control output 1 polarity
(DO assignment bank)
OT1.7
0: Direct
1: Reverse
0 Advanced
Control output 2 polarity
(DO assignment bank)
OT2.7
0
Event output 1 polarity
(DO assignment bank)
EV1.7
0
Event output 2 polarity
(DO assignment bank)
EV2.7
0
Event output 3 polarity
(DO assignment bank)
EV3.7
0
• If relay output or voltage pulse output is set as the control output by the model
No. and if one of functions 1 to 4 is set for the operation type of control outputs
1–2 (ot1.1 to ot2.1), the polarity setting of control outputs 1–2 (ot1.7 to ot2.7) is
displayed and can be changed.
• If a model with event relay outputs is used and if one of functions 1 to 4 is set for
the operation type of event outputs 1–3 (ev1.1 to ev3.1), the polarity setting of
event outputs 1–3 (ev1.7 to ev3.7) is displayed and can be changed.

Latch
Whether to latch the output when it is ON or OFF can be specified.
Item (bank) Display Description Initial value User level
Control output 1 latch
(DO assignment bank)
OT1.8
0: Do not latch
1: Latch when ON
2: Latch when OFF (except for initialization
at power-on)
0 Advanced
Control output 2 latch
(DO assignment bank)
OT2.8
0
Event output 1 latch
(DO assignment bank)
EV1.8
0
Event output 2 latch
(DO assignment bank)
EV2.8
0
Event output 3 latch
(DO assignment bank)
EV3.8
0
• If relay output or voltage pulse output is set as the control output by the model
No. and if one of functions 1 to 4 is set for the operation type of control outputs
1–2 (ot1.1 to ot2.1), the latch operation setting of control outputs 1–2 (ot1.8 to
ot2.8) is displayed and can be changed.
• If a model with event relay outputs is used and if one of functions 1 to 4 is set
for the operation type of event outputs 1–3 (ev1.1 to ev3.1), the latch operation
setting of event outputs 1–3 (ev1.8 to ev3.8) is displayed and can be changed.
