5-85
Chapter 5. Functions
5 - 11 Continuous output
The following is a functional block diagram for continuous output.
Output range type (Setup bank:
C42
,
C47
)
Output type (Setup bank:
C43
,
C48
)
Output scaling low/high limit (Setup bank:
C44
,
C45
,
C49
,
C50
)
Continuous output (current output)
Output range
The output range can be set for the current output.
Item (bank) Display Description Initial value User level
Control output 1 range
(setup bank)
C 42
1: 4 to 20 mA
2: 0 to 20 mA
1 Simple,
standard,
advanced
Control output 2 range
(setup bank)
C 47
1
• These items are displayed and the settings can be changed if current output is set
as the control output.
