5-86
Chapter 5. Functions
Output type
The type of current output can be set.
Item (bank) Display Description Initial value User level
Control output 1 type
(setup bank)
C 43
0: MV
1: Heating MV (for heating/cooling control)
2: Cooling MV (for heating/cooling control)
3: PV
4: PV (before applying ratio, bias, filter)
5: SP
6: Deviation (PV − SP)
7: CT1 current
8: CT2 current
9: Invalid
10: SP+MV
11: PV+MV
0 Simple,
standard,
advanced
Control output 2 type
(setup bank)
C 48
3
• These items are displayed and the settings can be changed if current output is set
as the control output.
• The MV scaling width is used for calculation of SP + MV and PV + MV.
MV scaling width (p.5-88) (for details)
