5-41
Chapter 5. Functions
STEP time unit
The time unit of a SOAK segment in a step operation can be specified.
Item (bank) Display Description Initial value User level
STEP time unit
(setup bank)
C 33
0: 0.1 s
1: 1 s (the operation display shows min. S)
2: 1 min (the operation display shows h. Min)
0 Advanced
• 0: The unit of the soak time setting in the SP bank will be 0.1 s.
• 1: The unit of the soak time setting in the SP bank will be seconds. The time
remaining in the step is displayed in the format MM.SS (minutes.seconds).
• 2: The unit of the soak time setting in the SP bank will be minutes. The time
remaining in the step is displayed in the format HH.MM (hours.minutes).
Handling Precautions
• The time remaining in the step is displayed in the unit set by “STEP time
unit,” regardless of whether the process is in RAMP or SOAK.
• If 1 is set, and the time remaining in the step is more than 99 minutes 59
seconds, 99.99 will be displayed.
• If 2 is set, and the time remaining in the step is more than 99 hours 59
minutes, 99.99 will be displayed.
