Chapter 6. Displayed Items and Settings
SP bank
Bank selection: SP
Display Item Description Initial
value
User
level
Notes
SP-1
SP (for LSP1)
SP low limit (C07) to SP high limit (C08)
0 0
PID.1
PID group No.
(for LSP1)
1 to 8 1 1
Displayed for PID control (CtrL
= 1)
RMP.1
Ramp (for LSP1) 0 to 9999
(The decimal point position is
determined by the decimal point position
of the PV and the SP ramp unit (C33).)
0 1
Displayed if SP ramp type (C31) is
set to 1 or more.
TIM.1
Soak time (for LSP1) 0.0 to 999.9 (when STEP time unit = 0.1 s)
0 to 9999 (when STEP time unit = 1 s or
1 min)
0 1
Displayed if SP ramp type (C31) is
set to 2 or more.
SP-2
SP (for LSP2) Same as LSP group 1 0 0 Displayed if LSP system group
(C30) is set to 2 or more and the
conditions for LSP1 described
above are met.
PID.2
PID group No.
(for LSP2)
1 1
RMP.2
Ramp (for LSP2) 0 1
TIM.2
Soak time (for LSP2) 0 1
SP-3
SP (for LSP3) Same as LSP group 1 0 0 Displayed if LSP system group
(C30) is set to 3 or more and the
conditions for LSP1 described
above are met.
PID.3
PID group No.
(for LSP3)
1 1
RMP.3
Ramp (for LSP3) 0 1
TIM.3
Soak time (for LSP3) 0 1
SP-4
SP (for LSP4) Same as LSP group 1 0 0 Displayed if LSP system group
(C30) is set to 4 or more and the
conditions for LSP1 described
above are met.
PID.4
PID group No.
(for LSP4)
1 1
RMP.4
Ramp (for LSP4) 0 1
TIM.4
Soak time (for LSP4) 0 1
