5-90
Chapter 5. Functions

CT operation type
Different operations can be set for CT inputs 1 and 2.
Item (bank) Display Description Initial value User level
CT1 operation type
(setup bank)
C 36
0: Heater burnout detection
1: Current measurement
0 Simple,
standard,
advanced
CT2 operation type
(setup bank)
C 39
0
• These items are displayed and the settings can be changed if a model with two CT
inputs is used.
• If current measurement is selected, the current when the output is ON is updated
regardless of the ON/OFF status of the output, and the current when the output is
OFF is always 0.0 A.

CT output
When the CT operation type is heater burnout detection, an output whose ON/OFF
is monitored can be specified.
Item (bank) Display Description Initial value User level
CT1 output
(setup bank)
C 37
0: Control output 1
1: Control output 2
2: Event output 1
3: Event output 2
4: Event output 3
0 Simple,
standard,
advanced
CT2 output
(setup bank)
C 40
0
• These items are displayed and the settings can be changed if a model with two CT
inputs is used and the CT operation type is set to heater burnout detection.

CT measurement wait time
When the CT operation type is heater burnout detection, the time from the change
in the output ON/OFF status to the start of the current measurement can be set.
Item (bank) Display Description Initial value User level
CT1 measurement wait time
(setup bank)
C 38
30 to 300 ms 30 ms Simple,
standard,
advanced
CT2 measurement wait time
(setup bank)
C 41
30 ms
• These items are displayed and the settings can be changed if a model with two CT
inputs is used and the CT operation type is set to heater burnout detection.
• Current measurement starts when the measurement waiting time elapses after the
change in the ON/OFF status of the monitored output, and it ends when 100 ms
elapses.
