5-95
Chapter 5. Functions
PV/SP display setup
Whether to show PV- and SP-related settings on the operation display can be
selected.
Item (bank) Display Description Initial value User level
PV/SP display setup
(setup bank)
C 74
Whether to show the following items on
the operation display is determined by the
sum of the weights shown below.
Bit 0: PV
No: 0. Yes: +1
Bit 1: SP
No: 0. Yes: +2
Bit 2: LSP group No.
No: 0. Yes: +4
Invalid settings: 0, +8
15 Standard,
advanced
2
3
2
2
2
1
2
0
• If Smart Loader Package model SLP-C1F is used, the setting for C74 (PV/SP
display setup) can be specified not only by a numerical value but also by bit input.
Handling Precautions
• Even if LSP group No. display is enabled, if C30 (LSP system group) is set to
1, LSP group numbers are not displayed.
Undefined
LSP group No. display
SP display
PV display
