5-98
Chapter 5. Functions

CT input current display setup
Whether to show the CT current on the operation display can be selected.
Item (bank) Display Description Initial value User level
CT input current display setup
(setup bank)
C 78
0: Do not show the CT current on the
operation display
1: Show the CT1 current on the operation
display
2: Show the CT1 and CT2 currents on the
operation display
1 Standard,
advanced
• This item is displayed and the setting can be changed if a model with two CT
inputs is used.

User level
What is displayed on the console can be restricted by specifying the user level. The
higher the setting, the more displayed items.
Item (bank) Display Description Initial value User level
User level
(setup bank)
C 79
0: Simple
1: Standard
2: Advanced
0 Simple,
standard,
advanced

Status indicator
The function of the status indicator can be selected.
Item (bank) Display Description Initial value User level
Status indicator
(setup bank)
C 80
0: Not used (always off)
1: Blinks when sending RS-485
communication data
2: Blinks when receiving RS-485
communication data
3: OR (logical sum) of all DI states
4: Always OFF
0 Advanced
