Azbil C1M - Temperature Unit

5-5
Chapter 5. Functions
z
PV input range table (DC voltage/current)
C01
setting
Sensor type Range*
1
C04
display*
2
C04
setting
range
C04 initial
value*
2
84 0–1 V The scaling range is −1999 to
+9999.
✓
0–3 0
86 1–5 V
✓
0–3 0
87 0–5 V
✓
0–3 0
88 0–10 V
✓
0–3 0
89 0–20 mA
✓
0–3 0
90 4–20 mA
✓
0–3 0
*1. If the display range is exceeded, this device continues displaying the maximum or
minimum value that can be displayed.
*2. C04 is the setting of the decimal point position of the PV.
*3. C04 is not reset to the initial value when C01 is changed.
Handling Precautions
• When the range No. is set, the initial setting for the PV decimal point position
and the range that are shown in the tables above apply.
PV decimal point
position (p.5-7) (for details on PV decimal point position)
• Be sure to specify the correct setting for C01 according to the sensor type
and range. Otherwise, abnormal output may occur due to a large error in
temperature.
•
Chapter 14. Specifications (for the accuracy of each PV input range type)

Temperature unit
When the PV input range type is thermocouple or RTD, the temperature unit can be
selected.
Item (bank) Display Description Initial value User level
Temperature unit (Setup bank)
C 02
0: Celsius (˚C)
1: Fahrenheit (˚F)
0 Simple,
standard,
advanced
• When the PV input range type is thermocouple or RTD, the display and setting
can be configured.
