Chapter 6. Displayed Items and Settings
6 - 1 Operation Settings
Meaning of user level settings
0: Simple configuration, 1: Standard configuration, 2: Advanced configuration
Operation settings
Display Item Description Initial
value
User
level
Notes
Upper display:
PV
Lower display:
SP
SP
(target value)
SP low limit (C07) to SP high limit (C08)
0 0 Whether to display can be
selected by the PV/SP value
display setting (C74).
LSP1
Lower display:
LSP
LSP No.
(the last digit)
From 1 to the number set for LSP system
group (C30, max. = 8)
1 0 Displayed if LSP system group
(C30) is set to 2 or more.
The lower display shows the LSP
for the LSP group.
Whether to display can be
selected by the PV/SP value
display setting (C74).
ST.1-
(display example)
Lower display:
Step remaining
time
Step No., step
remaining time
Setting cannot be changed
The upper display indicates the step No.
(1–8) to the right of ST and tells whether
the process is ramp-up, ramp-down, or
soak.
The lower display shows the remaining
time for the soak or ramp.
- 0 The time remaining in the step
is displayed in the unit set by
STEP time unit (C33) regardless
of whether the current process is
ramp or soak.
If the unit is 1 s: min.s
If the unit is 1 min: h.min
OUT
MV
(Manipulated
Variable)
−10.0 to +110.0 %
Setting cannot be changed in AUTO
mode
(the setting does not blink)
Setting can be changed in MANUAL
mode
(the setting blinks)
- 0
In ON/OFF control (CtrL = 0),
100.0 is displayed when ON and
0.0 is displayed when OFF.
Whether to display can be
selected by the MV display
setting (C75).
HEAT
Heat MV
(Manipulated
Variable)
Setting cannot be changed - 0 Displayed if heat/cool control is
used (C26 ≠ 0).
Whether to display can be
selected by the MV display
setting (C75).
COOL
Cool MV
(Manipulated
Variable)
Setting cannot be changed - 0
Upper display:
PV
AT 1
AT progress
(the last digit*)
Setting cannot be changed
x to 1: AT is running (the value
decrements)
0: AT is complete
- 0 Displayed if AT is running
(display continues even after AT
ends).
Whether to display can be
selected by the MV display
setting (C75).
CT1
Current transformer
(CT) input 1 current
Setting cannot be changed - 0 Displayed if a model with two CT
inputs is used.
Whether to display can be
selected by the CT display
setting (C78).
CT2
Current transformer
(CT) input 2 current
Setting cannot be changed - 0
E1
Internal event 1
main setting
The range of settings differs depending
on the operation type of the internal
event.
0 to 9999 U: An absolute value is set
−199.9 to + 999.9 %: MV
−1999 to +9999 U: Other than the above
0 0 The settings required for
the internal event type are
displayed.
Whether to display can be
selected by the event display
setting (C76).
E1.SB
Internal event 1
sub-setting
0 0
