6-27
Chapter 6. Displayed Items and Settings
Display Item Description Initial
value
User
level
Notes
E4.C1
Internal event 4
conf. 1 operation
type
Same as internal event 1 configuration 1 0 0
E4.C2
Internal event 4
conf. 2
1st digit:
Direct/reverse
2nd digit: Standby
3rd digit:
Event state in
READY mode
4th digit: Undefined
Same as internal event 1 configuration 2 0000 0
E4.C3
Internal event 4
conf. 3
1st digit: Alarm OR
2nd digit: Special OFF
3rd digit:
Delay time unit
4th digit: Undefined
Same as internal event 1 configuration 3 0000 2
E5.C1
Internal event 5
conf. 1 operation
type
Same as internal event 1 configuration 1 0 0
E5.C2
Internal event 5
conf. 2
1st digit:
Direct/reverse
2nd digit: Standby
3rd digit:
Event state in
READY mode
4th digit: Undefined
Same as internal event 1 configuration 2 0000 0
E5.C3
Internal event 5
conf. 3
1st digit: Alarm OR
2nd digit: Special OFF
3rd digit:
Delay time unit
4th digit: Undefined
Same as internal event 1 configuration 3 0000 2
