Chapter 6. Displayed Items and Settings
Display Item Description Initial
value
User
level
Notes
E1.C3
Internal event 1
conf. 3
“1st digit” (2nd, etc.) means the first digit
(etc.) from the right.
2
1st digit: Alarm OR 0: None
1: Alarm direct + OR operation
2: Alarm direct + AND operation
3: Alarm reverse + OR operation
4: Alarm reverse + AND operation
0
2nd digit: Special OFF 0: No special OFF
1: If the main setting for the event is 0,
the event is OFF.
0
3rd digit:
Delay time unit
0: 0.1 s
1: 1 s
2: 1 min
0
4th digit: Undefined 0 0
E2.C1
Internal event 2
conf. 1 operation
type
Same as internal event 1 configuration 1 0 0
E2.C2
Internal event 2
conf. 2
1st digit:
Direct/reverse
2nd digit: Standby
3rd digit:
Event state in
READY mode
4th digit: Undefined
0000 0
E2.C3
Internal event 2
conf. 3
1st digit: Alarm OR
2nd digit: Special OFF
3rd digit:
Delay time unit
4th digit: Undefined
Same as internal event 1 configuration 3 0000 2
E3.C1
Internal event 3
conf. 1 operation
type
Same as internal event 1 configuration 1 0 0
E3.C2
Internal event 3
conf. 2
1st digit:
Direct/reverse
2nd digit: Standby
3rd digit:
Event state in
READY mode
4th digit: Undefined
Same as internal event 1 configuration 2 0000 0
E3.C3
Internal event 3
conf. 3
1st digit: Alarm OR
2nd digit: Special OFF
3rd digit:
Delay time unit
4th digit: Undefined
Same as internal event 1 configuration 3 0000 2
