5-2
Chapter 5. Functions

PV input range type
For thermocouple and resistance temperature detector, the sensor type and the
temperature range can be selected.
For DC voltage and DC current, the signal type can be selected.
Item (bank) Display Description Initial value User level
PV input range type
(setup bank)
C 01
See the PV input range table. Differs depending on
the PV input type*
specified by the
model No.
Simple,
standard,
advanced
* For T (thermocouple) = 1, for R (RTD) = 41, for L (DC voltage/current) = 88
z
PV input range table (thermocouple)
C01
setting
Sensor type Range (Celsius)*
1
C04
display*
2
C04
setting
range
C04 initial
value*
3
1 K −200 to +1200 °C - (Fixed) 0
2 K 0 to 1200 °C - (Fixed) 0
3 K 0.0 to 800.0 °C
✓
0–1 0
4 K 0.0 to 600.0 °C
✓
0–1 0
5 K 0.0 to 400.0 °C
✓
0–1 0
6 K −200.0 to +400.0 °C
✓
0–1 0
9 J 0.0 to 800.0 °C
✓
0–1 0
10 J 0.0 to 600.0 °C
✓
0–1 0
11 J −200.0 to +400.0 °C
✓
0–1 0
13 E 0.0 to 600.0 °C
✓
0–1 0
14 T −200.0 to +400.0 °C
✓
0–1 0
15 R*
4
0 to 1600 °C - (Fixed) 0
16 S*
4
0 to 1600 °C - (Fixed) 0
17 B*
5
0 to 1800 °C - (Fixed) 0
18 N 0 to 1300 °C - (Fixed) 0
19 PLII 0 to 1300 °C - (Fixed) 0
20 WRe5-26 0 to 1400 °C - (Fixed) 0
21 WRe5-26 0 to 2300 °C - (Fixed) 0
23 PR40-20*
6
0 to 1900 °C - (Fixed) 0
24 DIN U −200.0 to +400.0 °C
✓
0–1 0
25 DIN L −100.0 to +800.0 °C
✓
0–1 0
*1. If the display range is exceeded, this device continues displaying the maximum or
minimum value that can be displayed.
*2. C04 is the setting of the decimal point position of the PV.
*3. C04 is reset to the initial value when C01 is changed.
*4. Accuracy Below 200 °C: ±9 °C
*5. Accuracy Below 260 °C: ±80 °C (reference value), 260 °C to below 600 °C: ±12 ° C, 600 °C to
below 1000 °C: ±6 °C, 1000 °C or more: ±4.5 °C. Temperatures below 20 °C are not displayed.
*6. Accuracy Below 400 °C: not specified, 400 °C to below 1100 °C: ±40 °C, 1100 °C or more:
±12°C.
