6-33
Chapter 6. Displayed Items and Settings
Display Item Description Initial
value
User
level
Notes
DI5.3
Internal contact 5
input assignment A
Same as internal contact 1 input
assignment A to D
0 to 33
3 2 Displayed if internal contact 5
input bit function is set to one of
functions 1–4 (dI2.2 ≠ 0).
DI5.4
Internal contact 5
input assignment B
0 2
DI5.5
Internal contact 5
input assignment C
0 2
DI5.6
Internal contact 5
input assignment D
0 2
DI5.7
Internal contact 5
polarity A to D
“1st digit” (2nd, etc.) means the first digit
(etc.) from the right.
2
1st digit: Polarity A
(polarity of input
assignment A)
0: Direct
1: Reverse
0
2nd digit: Polarity B
(polarity of input
assignment B)
0
3rd digit: Polarity C
(polarity of input
assignment C)
0
4th digit: Polarity D
(polarity of input
assignment D)
0
DI5.8
Internal contact 5
polarity
0: Direct
1: Reverse
0 2
DI5.9
Internal contact 5
internal event No.
assignment
0: All internal events
1 to 5: Internal event No.
0 2 Displayed if internal contact 5
operation type is set to timer
stop/start (dI21 = 17).
