Chapter 6. Displayed Items and Settings
Display Item Description Initial
value
User
level
Notes
Ot1.6
Control output 1
polarity A to D
“1st digit” (2nd, etc.) means the first digit
(etc.) from the right.
2 Displayed if relay output or
voltage pulse output is set as
control output 1 by the model
No. and control output 1
operation type is set to one of
functions 1–4 (Ot1.1 > 2).
1st digit: Polarity A 0: Direct
1: Reverse
0
2nd digit: Polarity B 0
3rd digit: Polarity C 0
4th digit: Polarity D 0
Ot1.7
Control output 1
polarity
0: Direct
1: Reverse
0 2
Ot1.8
Control output 1
latch
0: Do not latch
1: Latch when ON
2: Latch when OFF (except for
initialization at power-on)
0 2
Ot2.1
Control output 2
operation type
Same as control output 1 operation type
0: Default output
1: MV1
2: MV2
3-6: Functions 1-4
0 2 Displayed if voltage pulse
output is set as control output 2
by the model No.
For control output 2, the default
output is MV2.
Ot2.2
Control output 2
output assignment A
Same as control output 1 output
assignment A to D
0 to 49
15 2 Displayed if voltage pulse
output is set as control output
2 by the model No. and control
output 2 operation type is set to
one of functions 1–4 (ot2.1 > 2).
Ot2.3
Control output 2
output assignment B
0 2
Ot2.4
Control output 2
output assignment C
0 2
Ot2.5
Control output 2
output assignment D
0 2
Ot2.6
Control output 2
polarity A to D
“1st digit” (2nd, etc.) means the first digit
(etc.) from the right.
2
1st digit: Polarity A 0: Direct
1: Reverse
0
2nd digit: Polarity B 0
3rd digit: Polarity C 0
4th digit: Polarity D 0
Ot2.7
Control output 2
polarity
0: Direct
1: Reverse
0 2
Ot2.8
Control output 2
latch
0: Do not latch
1: Latch when ON
2: Latch when OFF (except for
initialization at power-on)
0 2
Ev1.1
Event output 1
operation type
Same as control output 1 operation type
0: Default output
1: MV1
2: MV2
3-6: Functions 1-4
0 2 Displayed if a model with event
output 1 is used.
For event output 1, the default
output is internal event 1.
