Chapter 5. Functions
z Sample settings
• Event
Event Display Internal event 1 Internal event 2
Operation type
E
_
.C1
32: Timer 4: Deviation high limit
Direct/reverse
E
_
.C2
---- 0: Direct
Standby
E
_
.C2
---- 0: No standby
Event state in
READY
E
_
.C2
0: Continues 0: Continues
Alarm OR
E
_
.C3
0: None 0: None
Special OFF
E
_
.C3
---- 0: No special OFF
Delay time unit
E
_
.C3
2: 1 min 0: 0.1 s
Event main
setting (low limit)
E
_
---- 0
Event sub-setting
(high limit)
E
_
.SB
---- ----
Hysteresis
E
_
.HY
---- 5
ON delay time
E
_
.ON
30 0
OFF delay time
E
_
.OF
0 0
_: Internal event No.
• DI assignment
DI assignment Display Internal contact 1 Internal contact 2
Operation type
DI
_
.1
17: Timer stop/start 7: RUN/READY
Input bit function
DI
_
.2
1: Function 1, (A and B) or (C
and D)
1: Function 1, (A and B) or (C
and D)
Input assignment
A
DI
_
.3
2: DI1 2: DI1
Input assignment
B
DI
_
.4
11: Internal event 2 (setting
= 4: Deviation high limit)
10: Internal event 1 (setting
= 32: Timer (status))
Input assignment
C
DI
_
.5
0: Normally open (normally
OFF = 0)
0: Normally open (normally
OFF = 0)
Input assignment
D
DI
_
.6
0: Normally open (normally
OFF = 0)
0: Normally open (normally
OFF = 0)
Polarity A
DI
_
.7
0: Direct 0: Direct
Polarity B
DI
_
.7
0: Direct 1: Reverse
Polarity C
DI
_
.7
0: Direct 0: Direct
Polarity D
DI
_
.7
0: Direct 0: Direct
Polarity
DI
_
.8
0: Direct 1: Reverse
Internal event No.
assignment
DI
_
.9
1 ----
_
: Internal contact No.
