14-5
Chapter 14. Specifications
z
Operating conditions
Item Description
Ambient temperature −10 to +55 °C (−10 to 45 °C for gang-mounting)
Ambient humidity 10–85 % RH (without condensation or freezing)
Power 85–264 V AC, 50/60 Hz ±2 Hz
(Rated power: 100–240 V AC, 50/60 Hz)
Vibration 0–5 m/s
2
(10–60 Hz for 2 h each in x, y, and z
directions)
Shock 0–100 m/s
2
Mounting angle Reference plane ±10°
z
Transport and storage conditions
Item Description
Ambient temperature −20 to +70 °C
Ambient humidity 10–85 % RH (without condensation or freezing,
protected from humidity and dust)
Vibration 0–10 m/s
2
(10–150 Hz for 2 h each in X, Y, and Z
directions)
Shock 0–300 m/s
2
(vertically 3 times)
Drop test Drop height 60 cm (free fall on 1 corner, 3 edges,
6 sides)
z
Other specifications
Item Description
Protection class IP66 (device front side)
(only when individually mounted in a panel using
the included gasket)
Power consumption 8 VA or less (6 VA at 100 V AC, 8 VA at 264 V AC)
Allowable transient power loss 20 ms max.
Elevation 2000 m max.
Mass Approximately 130 g (including dedicated
mounting bracket)
Terminal screw tightening torque 0.6 ±0.1 N·m
Standards compliance EN 61010-1 (low-voltage directive)
EN IEC63000 (RoHS)
EN 61326-1 (for use in industrial locations) (EMC
Directive)
During EMC testing, the indication or output may
fluctuate by the equivalent of ±10 % FS.
Overvoltage category II (IEC 60364-4-443, IEC 60664-1)
Allowable pollution degree 2
Insulation resistance 20 MΩ min.
(Power terminals, and between power terminals
and isolated I/O terminals)
(with a 500 V DC insulation resistance tester)
Dielectric strength 1500 V AC for 1 minute
Allowable transient power loss 20 ms max.
Power-on inrush current 18 A max. / 1.5 ms max.
Case material/color Modified PPE/black
Protective sheet material/color Polyester film/black
