Numeric value and character display on LCD
Numeric values: The 7-segment LCD expresses numeric values as follows:
0 1 2 3 4
5 6 7 8 9
Alphabetical characters: The 7-segment LCD expresses alphabetical characters shown below. There
are some alphabetical characters which are not displayed on the LED.
A B C D E
a b c d e
F G H I J
f g h i j
K L M N O
k l m n o
P Q R S T
p q r s t
U V Y Z －
u v y z
Handling Precautions:
• As shown above, the following are shown in the same way: the number 2
and the letter Z, the number 5 and the letter S, and the number 9 and the
letter Q.
