4-12
Chapter 4. Wiring
4 - 2 Cables
For thermocouple input, connect the unshielded wires of the thermocouple to the PV input terminals.
If a thermocouple with a terminal block is used, or if the wiring distance is long, use compensating lead wires for
connection with the terminals of this device.
Use shielded compensating lead wires.
• For inputs and outputs other than thermocouples, use JCS 4364 cables for low-
power instruments or the equivalent (generally called twisted shielded cable for
instrumentation use).
The following cables are recommended.
Fujikura Dia Cable Ltd. 2 cores IPEV-S-0.9 mm
2
×1P
3 cores ITEV-S-0.9 mm
2
×1T
Sumiden HST Cable Co., Ltd. 2 cores JKPEV-S-0.9 mm
2
×1P
Note: The model No. of the recommended cable may change without notice, so please
contact the manufacturer.
• If there is relatively little electromagnetic induction noise, shielded multi-core
microphone cables (MVVS) can be used.
