Envelope Feeder Attachment-B1
7-15
Handling Options
7
Envelope Feeder Attachment-B1
Parts and Their Functions
When the Envelope Feeder Attachment is attached to Paper Drawer 1:
1 Left guide
Align to the length of envelopes being loaded.
2 Envelope receptacle
3 Back width guide
4 Front width guide
5 Size switch
Select either “ENV.1” or “ENV.2” for the envelope
cassette.
1
2
3
5
4
