7
Saddle Finisher-G1/Puncher Unit-K1
7-51
Handling Options
NOTE
• The hole punched area is shown below.
• The distance between the punch holes is shown in the illustration below.
ABC
ABC
V
ABC
V
ABC
Hole punched
area
Hole punched
area
Hole punched
area
Hole punched
area
FeederPlaten glass
4-1/4"
(108mm)
4-1/4"
(108mm)
3 holes
2-3/4"
(70mm)
2 holes
