Chery Automobile Co., Ltd.
46 - SEAT
46–16
46
5. Remove the power seat position adjust switch (for driver side) (if equipped).
a. Using a screwdriver wrapped with protective tape, pry
up the claw on the power seat position adjust switch,
and remove the power seat position adjust switch.
6. Remove the driver seat reclining adjuster handle.
a. Using a screwdriver wrapped with protective tape, pry
up the seat reclining adjuster handle cover (1).
b. Remove 2 fixing screws (arrow) from the seat
reclining adjuster handle, and remove the driver seat
reclining adjuster handle.
(Tightening torque: 4.8 ± 0.5 N·m)
7. Remove the power seat reclining adjust switch (for driver side) (if equipped).
a. Using a screwdriver wrapped with protective tape, pry
up the claw on the power seat reclining adjust switch,
and remove the power seat reclining adjust switch.
To Next Page
