Cisco 500 Series Administration Guide

Cisco 500 Series Stackable Managed Switch Administration Guide 3
Contents
Rebooting the Device 108
Routing Resources 110
Health 114
Diagnostics 116
Discovery - Bonjour 116
Discovery - LLDP 117
Discovery - CDP 117
Ping 117
Traceroute 119
Chapter 7: Administration: Time Settings 122
System Time Options 123
SNTP Modes 124
Configuring System Time 125
Chapter 8: Administration: Diagnostics 136
Copper Ports Tests 136
Displaying Optical Module Status 138
Configuring Port and VLAN Mirroring 140
Viewing CPU Utilization and Secure Core Technology 141
Chapter 9: Administration: Discovery 144
Bonjour 144
LLDP and CDP 146
Configuring LLDP 147
Configuring CDP 168
CDP Statistics 176
Chapter 10: Port Management 178
Configuring Ports 178

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
