Spanning Tree
MSTP Instance Settings
Cisco 500 Series Managed Switch Administration Guide 306
15
For those VLANs that are not explicitly mapped to one of the MST instances, the
device automatically maps them to the CIST (Core and Internal Spanning Tree)
instance. The CIST instance is MST instance 0.
To map VLANs to MST Instances:
STEP 1 Click Spanning Tree > VLAN to MSTP Instance.
The VLAN to MSTP Instance page contains the following fields:
• MSTP Instance ID—All MST instances are displayed.
• VLANs—All VLANs belonging to the MST instance are displayed.
STEP 2 To add a VLAN to an MSTP instance, select the MST instance, and click Edit.
STEP 3 Enter the parameters:
• MSTP Instance ID—Select the MST instance.
• VLANs—Define the VLANs being mapped to this MST instance.
• Action—Define whether to Add (map) the VLAN to the MST instance or
Remove it.
STEP 4 Click Apply. The MSTP VLAN mappings are defined, and the Running
Configuration file is updated.
MSTP Instance Settings
The MSTP Instance Settings page
enables
you to configure and view parameters
per MST instance. This is the per-instance equivalent to the Configuring STP
Status and Global Settings.
To enter MSTP instance settings:
STEP 1 Click Spanning Tree > MSTP Instance Settings.
STEP 2 Enter the parameters.
• Instance ID—Select an MST instance to be displayed and defined.
