Administration: Stack Management
Stack Topology
Cisco 500 Series Stackable Managed Switch Administration Guide 74
5
Unit LEDs
The device has 4 LEDs marked as 1, 2, 3, 4 that are used to display the unit ID of
each unit (e.g. on Unit ID 1, LED 1 is ON and the other LEDs are OFF). To support unit
IDs greater than 4, the LED display is changed in accordance to the below
definition:
• Units 1-4: LEDs 1-4 are lit, respectively.
• Unit 5: LED 1 and 4 are lit.
• Unit 6: LED 2 and 4 are lit.
• Unit 7: LED 3 and 4 are lit.
• Unit 8: LED 1, 3, and 4 are lit.
Stack Topology
Types of Stack Topology
The units in a stack can be connected in one of the following types of topologies:
• Chain To p o l o g y —Each unit is connected to the neighboring unit, but there is
no cable connection between the first and last unit. See “Stack
Architecture (Chain Topology)” shows a chain topology.
• Ring Topology—Each unit is connected to the neighboring unit. The last unit
is connected to the first unit. The following shows a ring topology of an
eight-unit stack:

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
