Cisco 500 Series Administration Guide

Managing MAC Address Tables
Reserved MAC Addresses
313 Cisco 500 Series Managed Switch Administration Guide
16
Reserved MAC Addresses
When the device receives a frame with a destination MAC address that belongs to
a reserved range (per the IEEE standard), the frame can be discarded or bridged.
The entry in the Reserved MAC Address Table can either specify the reserved
MAC address or the reserved MAC address and a frame type:
To add an entry for a reserved MAC address:
STEP 1 Click MAC Address Tables > Reserved MAC Addresses.
STEP 2 Click Add.
STEP 3 Enter the values for the following fields:
• MAC Address—Select the MAC address to be reserved.
• Frame Type—Select a frame type based on the following criteria:
-
Ethernet V2 —Applies to Ethernet V2 packets with the specific MAC
address.
-
LLC —Applies to Logical Link Control (LLC) packets with the specific
MAC address.
-
LLC-SNAP —Applies to Logical Link Control/Sub-Network Access
Protocol (LLC-SNAP) packets with the specific MAC address.
-
All —Applies to all packets with the specific MAC address.
• Action—Select one of the following actions to be taken upon receiving a
packet that matches the selected criteria:
-
Bridge —Forward the packet to all VLAN members.
-
Discard —Delete the packet.
STEP 4 Click Apply. A new MAC address is reserved.

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
