Cisco 500 Series Administration Guide

Administration
Diagnostics
Cisco 500 Series Stackable Managed Switch Administration Guide 116
6
- Warning—The temperature is between the warning threshold to the
critical threshold.
- Critical—Temperature is above the critical threshold
If the device is in Standalone mode, the following fields are displayed:
• Fan Status—Fan status. The following values are possible:
- OK—Fan(s) are operating normally.
- Fail—Fan(s) are not operating correctly.
- N/A—Fan is not applicable for the specific model.
• Fan Direction—The direction that the fans are working in.
• Temp erature—The options are:
- OK—The temperature is below the warning threshold.
- Warning—The temperature is between the warning threshold to the
critical threshold.
- Critical—Temperature is above the critical threshold
If the device is in Native Stack mode, the Health page displays the above fields for
each unit:
Diagnostics
See Administration: Diagnostics.
Discovery - Bonjour
See Bonjour.

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
