VLAN Management
Customer Port Multicast TV VLAN
Cisco 500 Series Stackable Managed Switch Administration Guide 294
14
After a CPE VLAN is mapped to a Multicast VLAN, it can participate in IGMP
snooping.
To m a p C P E V L A N s :
STEP 1 Click VLAN Management > Customer Port Multicast TV VLAN > CPE VLAN to
VLAN.
STEP 2 Click Add.
STEP 3 Enter the following fields:
• CPE VLAN—Enter the VLAN defined on the CPE box.
• Multicast TV VLAN—Select the Multicast TV VLAN which is mapped to the
CPE VLAN.
STEP 4 Click Apply. CPE VLAN Mapping is modified, and written to the Running
Configuration file.
Port Multicast VLAN Membership
The ports associated with the Multicast VLANs must be configured as customer
ports (see Interface Settings).
To m a p p o r t s to M u l t i c a s t T V V L A N s :
STEP 1 Click VLAN Management > Customer Port Multicast TV VLAN > Port Multicast
VLAN Membership.
STEP 2 Select a VLAN from Multicast TV VLAN .
STEP 3 Select an interface from Interface Type.
STEP 4 The Candidate Customer Ports list contains all access ports configured on the
device. Move the required ports to the Member Customer Ports field.
Click Apply. The new settings are modified, and written to the Running
Configuration file.
