Cisco 500 Series Administration Guide

Security: 802.1X Authentication
Common Tasks
Cisco 500 Series Stackable Managed Switch Administration Guide 494
22
Common Tasks
Workflow 1: To enable 802.1x authentication on a port:
STEP 1 Click Security > 802.1X/MAC/Web Authentication > Properties.
STEP 2 Enable Port-based Authentication.
STEP 3 Select the Authentication Method .
STEP 4 Click Apply, and the Running Configuration file is updated.
STEP 5 Click Security > 802.1X/MAC/Web Authentication> Host and Session.
STEP 6 Select the required port and click Edit.
STEP 7 Set the Host Authentication mode.
STEP 8 Click Apply, and the Running Configuration file is updated.
STEP 9 Click Security > 802.1X/MAC/Web Authentication > Port Authentication.
STEP 10 Select a port, and click Edit.
STEP 11 Set the Administrative Port Control field to Auto.
STEP 12 Define the authentication methods.
STEP 13 Click Apply, and the Running Configuration file is updated.
Workflow 2: To configure traps
STEP 1 Click Security > 802.1X/MAC/Web Authentication > Properties.
STEP 2 Select the required traps.
STEP 3 Click Apply, and the Running Configuration file is updated.
Workflow 3: To configure 802.1x-based or Web-based authentication
STEP 1 Click Security > 802.1X/MAC/Web Authentication > Port Authentication .
STEP 2 Select the required port and click Edit.
STEP 3 Enter the fields required for the port.
The fields in this page are described in 802.1X Port Authentication.
