VLAN Management
Customer Port Multicast TV VLAN
Cisco 500 Series Stackable Managed Switch Administration Guide 292
14
STEP 3 Click Apply. Multicast TV VLAN settings are modified, and written to the Running
Configuration file.
Port Multicast VLAN Membership
To define the Multicast TV VLAN configuration:
STEP 1 Click VLAN Management > Access Port Multicast TV VLAN > Port Multicast VLAN
Membership.
STEP 2 Select a VLAN from Multicast TV VLAN..
STEP 3 Select an interface from Interface Type.
STEP 4 The Candidate Access Ports list contains all access ports configured on the
device. Move the required ports to the Member Access Ports field.
STEP 5 Click Apply. Multicast TV VLAN settings are modified, and written to the Running
Configuration file.
Customer Port Multicast TV VLAN
A triple play service provisions three broadband services, over a single
broadband connection:
• High-speed Internet access
• Video
• Voice
The triple play service is provisioned for service provider subscribers, while
keeping Layer 2-isolation between them.
Each subscriber has a CPE MUX box. The MUX has multiple access ports that are
connected to the subscriber's devices (PC, telephone and so on), and one network
port that is connected to the access device.
The box forwards the packets from the network port to the subscriber's devices
based on the VLAN tag of the packet. Each VLAN is mapped to one of the MUX
access ports.
