Cisco 500 Series Administration Guide

Security: 802.1X Authentication
802.1X Configuration Through the GUI
495 Cisco 500 Series Stackable Managed Switch Administration Guide
22
STEP 4 Click Apply, and the Running Configuration file is updated.
Use the Copy Settings button to copy settings from one port to another.
Workflow 4: To configure the quiet period
STEP 1 Click Security > 802.1X/MAC/Web Authentication > Port Authentication .
STEP 2 Select a port, and click Edit.
STEP 3 Enter the quiet period in the Quiet Period field.
STEP 4 Click Apply, and the Running Configuration file is updated.
Workflow 5: To configure the guest VLAN:
STEP 1 Click Security > 802.1X/MAC/Web Authentication > Properties.
STEP 2 Select Enable in the Guest VLAN field.
STEP 3 Select the guest VLAN in the Guest VLAN ID field.
STEP 4 Configure the Guest VLAN Timeout to be either Immediate or enter a value in the
User defined field.
STEP 5 Click Apply, and the Running Configuration file is updated.
Workflow 6: To configure unauthenticated VLANs
STEP 1 Click Security > 802.1X/MAC/Web Authentication > Properties.
STEP 2 Select a VLAN, and click Edit.
STEP 3 Select a VLAN.
STEP 4 Optionally, uncheck Authentication to make the VLAN an unauthenticated VLAN.
STEP 5 Click Apply, and the Running Configuration file is updated.
802.1X Configuration Through the GUI
NOTE Web-based authentication is only supported in Layer 2 mode on Sx300 and SG500
devices. On SG500XG and SG500X devices, it is supported in Native and
Advanced Hybrid XG mode

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
