Page #230 background image
Smartport
Configuring Smartport Using The Web-based Interface
Cisco 500 Series Stackable Managed Switch Administration Guide 228
12
Smartport Type Settings
Use the Smartport Type Settings page to edit the Smartport Type settings and
view the Macro Source.
By default, each Smartport type is associated with a pair of built-in Smartport
macros. See Smartport Types for further information on macro versus anti-macro.
Alternatively, you can associate your own pair of user-defined macros with
customized configurations to a Smartport type. User-defined macros can be
prepared only through CLI. You should refer to the CLI reference guide for details.
Built-in or user-defined macros can have parameters. The built-in macros have up
to three parameters.
Editing these parameters for the Smartport types applied by Auto Smartport from
the Smartport Type Settings page configures the default values for these
parameters. These defaults are used by Auto Smartport.
NOTE Changes to Auto Smartport types cause the new settings to be applied to
interfaces which have already been assigned that type by Auto Smartport. In this
case, binding an invalid macro or setting an invalid default parameter value causes
all ports of this Smartport type to become unknown.
STEP 1 Click Smartport > Smartport Type Settings.
STEP 2 To view the Smartport macro associated with a Smartport type, select a
Smartport type and click View Macro Source.
STEP 3 To modify the parameters of a macro or assign a user-defined macro, select a
Smartport type and click Edit.
STEP 4 Enter the fields.
• Port Type—Select a Smartport type.
• Macro Name—Displays the name of the Smartport macro currently
associated with the Smartport type.
• Macro Type—Select whether the pair of macro and anti-macro associated
with this Smartport type is built-in or user-defined.
• User Defined Macro—If desired, select the user-defined macro that is to be
associated with the selected Smartport type. The macro must have already
been paired with an anti-macro.
Pairing of the two macros is done by name and is described in the
Smartport Macro section.
