Cisco 500 Series - Voice Vlan Configuration

VLAN Management
Voice VLAN
283 Cisco 500 Series Stackable Managed Switch Administration Guide
14
Voice VLAN Configuration
This section describes how to configure voice VLAN. It covers the following
topics:
• Configuring Voice VLAN Properties
• Auto Voice VLAN Settings
• Telephony OUI
Configuring Voice VLAN Properties
Use the Voice VLAN Properties page for the following:
• View how voice VLAN is currently configured.
• Configure the VLAN ID of the Voice VLAN.
• Configure voice VLAN QoS settings.
• Configure the voice VLAN mode (Telephony OUI or Auto Voice VLAN).
• Configure how Auto Voice VLAN is triggered.
To view and configure Voice VLAN properties:
STEP 1 Click VLAN Management > Voice VLAN > Properties.
• The voice VLAN settings configured on the device are displayed in the Voice
VLAN Settings (Administrative Status) block.
• The voice VLAN settings that are actually being applied to the voice VLAN
deployment are displayed in the Voice VLAN Settings (Operational Status)
block.
STEP 2 Enter values for the following fields:
• Voice VLAN ID—Enter the VLAN that is to be the Voice VLAN.
NOTE Changes in the voice VLAN ID, CoS/802.1p, and/or DSCP cause the
device to advertise the administrative voice VLAN as a static voice VLAN. If
the option
Auto Voice VLAN Activation triggered by external Voice VLAN is
selected, then the default values need to be maintained.
• CoS/802.1p —Select a CoS/802.1p value that to be used by LLDP-MED as
a voice network policy. Refer to
Administration > Discovery > LLDP > LLDP
MED Network Policy
for additional details.
