Page #284 background image
VLAN Management
Voice VLAN
Cisco 500 Series Stackable Managed Switch Administration Guide 282
14
Workflow1: To configure Auto Voice VLAN:
STEP 1 Open the VLAN Management > Voice VLAN > Properties page.
STEP 2 Select the Voice VLAN ID. It cannot be set to VLAN ID 1 (this step is not required for
dynamic Voice VLAN).
STEP 3 Set Dynamic Voice VLAN to Enable Auto Voice VLAN.
STEP 4 Select the Auto Voice VLAN Activation method.
NOTE If the device is currently in Telephony OUI mode, you must disable it
before you can configure Auto Voice Vlan
STEP 5 Click Apply.
STEP 6 Configure Smartports as described in the Common Smartport Tasks section.
STEP 7 Configure LLDP/CDP as described in the Configuring LLDP and Configuring
CDP sections, respectively.
STEP 8 Enable the Smartport feature on the relevant ports using the Smartport > Interface
Settings page.
NOTE Step 7 and Step 8 are optional as they are enabled by default.
Workflow2: To configure the Telephony OUI Method
STEP 1 Open the VLAN Management > Voice VLAN > Properties page. Set Dynamic Voice
VLAN to Enable Telephony OUI.
NOTE If the device is currently in Auto Voice VLAN mode, you must disable
it before you can enable Telephony OUI.
STEP 2 Configure Telephony OUI in the Telephony OUI page.
STEP 3 Configure Telephony OUI VLAN membership for ports in the Telephony OUI
Interface page.
