Cisco 500 Series Administration Guide

Security
IP Source Guard
Cisco 500 Series Stackable Managed Switch Administration Guide 472
21
Enabling IP Source Guard
To enable IP Source Guard globally:
STEP 1 Click Security > IP Source Guard > Properties.
STEP 2 Select Enable to enable IP Source Guard globally.
STEP 3 Click Apply to enable IP Source Guard.
Configuring IP Source Guard on Interfaces
If IP Source Guard is enabled on an untrusted port/LAG, DHCP packets, allowed
by DHCP Snooping, are transmitted. If source IP address filtering is enabled,
packet transmission is permitted as follows:
• IPv4 traffic — Only IPv4 traffic with a source IP address that is associated
with the specific port is permitted.
• Non IPv4 traffic — All non-IPv4 traffic is permitted.
See Interactions with Other Features for more information about enabling IP
Source Guard on interfaces.
To configure IP Source Guard on interfaces:
STEP 1 Click Security > IP Source Guard > Interface Settings.
STEP 2 Select port/LAG from the Filter field and click Go. The ports/LAGs on this unit are
displayed along with the following:
• IP Source Guard —Indicates whether IP Source Guard is enabled on the
port.
• DHCP Snooping Trusted Interface—Indicates whether this is a DHCP trusted
interface.
STEP 3 Select the port/LAG and click Edit. Select Enable in the IP Source Guard field to
enable IP Source Guard on the interface.
STEP 4 Click Apply to copy the setting to the Running Configuration file.

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
