Smartport
Configuring Smartport Using The Web-based Interface
Cisco 500 Series Stackable Managed Switch Administration Guide 226
12
Workflow4: To rerun a Smartport macro after it has failed, perform the
following steps:
STEP 1 In the Interface Settings page, select an interface with Smartport type Unknown.
STEP 2 Click Show Diagnostics to see the problem.
STEP 3 Troubleshoot, then correct the problem. Consider the troubleshooting tip below.
STEP 4 Click Edit. A new window appears in which you can click Reset to reset the
interface.
STEP 5 Return to the main page and reapply the macro using either Reapply (for devices
that are not switches, routers or APs) or Reapply Smartport Macro (for switches,
routers or APs) to run the Smartport Macro on the interface.
A second method of resetting single or multiple unknown interfaces is:
STEP 1 In the Interface Settings page, select the Port Type equals to checkbox.
STEP 2 Select
Unknown
and click Go.
STEP 3 Click Reset All Unknown Smartports. Then reapply the macro as described above.
TIP The reason that the macro failed might be a conflict with a configuration on the
interface made prior to applying the macro (most often encountered with security
and storm-control settings), a wrong port type, a typo or an incorrect command
within the user-defined macro, or an invalid parameter setting. Parameters are
checked for neither type nor boundary prior to the attempt to apply the macro,
therefore, an incorrect or invalid input to a parameter value will almost assuredly
cause failure when applying the macro.
Configuring Smartport Using The Web-based Interface
The Smartport feature is configured in the Smartport > Properties, Smartport
Type Settings and Interface Settings pages.
For Voice VLAN configuration, see Voice VLAN.
For LLDP/CDP configuration, see the Configuring LLDP and Configuring CDP
sections, respectively.
