Smartport
Common Smartport Tasks
225 Cisco 500 Series Stackable Managed Switch Administration Guide
12
Workflow2: To configure an interface as a static Smartport, perform the
following steps:
STEP 1 To enable the Smartport feature on the interface, open the Smartport > Interface
Settings page.
STEP 2 Select the interface, and click Edit.
STEP 3 Select the Smartport type that is to be assigned to the interface in the Smartport
Application field.
STEP 4 Set the macro parameters as required.
STEP 5 Click Apply.
Workflow3: To adjust Smartport macro parameter defaults and/or bind a
user-defined macro pair to a Smartport type, perform the following
steps:
Through this procedure you can accomplish the following:
• View the macro source.
• Change parameter defaults.
• Restore the parameter defaults to the factory settings.
• Bind a user-defined macro pair (a macro and its corresponding anti-macro)
to a Smartport type.
1. Open the Smartport > Smartport Type Settings page.
2. Select the Smartport Type.
3. Click View Macro Source to view the current Smartport macro that is
associated with the selected Smartport Type.
4. Click Edit to open a new window in which you can bind user-defined macros to
the selected Smartport type and/or modify the default values of the parameters
in the macros bound to that Smartport type. These parameter default values are
used when Auto Smartport applies the selected Smartport type (if applicable)
to an interface.
5. In the Edit page, modify the fields.
6. Click Apply to rerun the macro if the parameters were changed, or Restore
Defaults to restore default parameter values to built-in macros if required.
