Cisco 500 Series Administration Guide

Quality of Service
Configuring QoS - General
Cisco 500 Series Stackable Managed Switch Administration Guide 614
28
To define the VLAN ingress rate limit:
STEP 1 Click Quality of Service > General > VLAN Ingress Rate Limit.
This page displays the VLAN Ingress Rate Limit Table.
STEP 2 Click Add.
STEP 3 Enter the parameters.
• VLAN ID—Select a VLAN.
• Committed Information Rate (CIR)—Enter the average maximum amount
of data that can be accepted into the VLAN in Kilobytes per second.
• Committed Burst Size (CBS)—Enter the maximum burst size of data for the
egress interface in bytes of data. This amount can be sent even if it
temporarily increases the bandwidth beyond the allowed limit. Cannot be
entered for LAGs.
STEP 4 Click Apply. The VLAN rate limit is added, and the Running Configuration file is
updated.
TCP Congestion Avoidance
The TCP Congestion Avoidance page enables activating a TCP congestion
avoidance algorithm. The algorithm breaks up or avoids TCP global
synchronization in a congested node, where the congestion is due to various
sources sending packets with the same byte count.
To configure TCP congestion avoidance:
STEP 1 Click Quality of Service > General > TCP Congestion Avoidance.
STEP 2 Click Enable to enable TCP congestion avoidance, and click Apply.

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
