Access Control
IPv6-Based ACLs
591 Cisco 500 Series Stackable Managed Switch Administration Guide
27
• IGMP—If the ACL is based on IGMP, select the IGMP message type to be
used for filtering purposes. Either select the message type by name or enter
the message type number:
- Any—All message types are accepted.
- Select from list—Select message type by name.
- IGMP Type to match—Number of message type that is to be used for
filtering purposes.
STEP 5 Click Apply. The IPv4-based ACE is saved to the Running Configuration file.
IPv6-Based ACLs
The IPv6-Based ACL page displays and enables the creation of IPv6 ACLs, which
check pure IPv6-based traffic. IPv6 ACLs do not check IPv6-over-IPv4 or ARP
packets.
NOTE ACLs are also used as the building elements of flow definitions for per-flow QoS
handling.
Defining an IPv6-based ACL
To define an IPv6-based ACL:
STEP 1 Click Access Control > IPv6-Based ACL.
This window contains the list of defined ACLs and their contents
STEP 2 Click Add.
STEP 3 Enter the name of a new ACL in the ACL Name field. The names are
case-sensitive.
STEP 4 Click Apply. The IPv6-based ACL is saved to the Running Configuration file.
Adding Rules (ACEs) for an IPv6-Based ACL
NOTE Each IPv6-based rule consumes two TCAM rules.

Cisco 500 Series Specifications

General

Model	Cisco 500 Series
Category	Switch
Mounting	Rack-mountable
Management	Web-based, CLI, SNMP
Ports	24, 48
Port Speed	10/100/1000 Mbps
PoE Support	Available on some models
Switching Capacity	Up to 176 Gbps
MAC Address Table Size	16, 000 entries
Security	ACLs, 802.1X
Quality of Service (QoS)	Yes
Dimensions	Varies by model
Weight	Varies by model
Humidity	10% to 90% non-condensing
Power Supply	Internal
Power Consumption	Varies by model
Jumbo Frame Support	Up to 9216 bytes
